Medium Voltage Fixed Panels

The equipments of these types of panels consists; simple disconnectors, switch disconnectors, disconnectors interruptible load, circuit breaker and measurement equipment to fit the needs and requests are made and assembled in the public distribution network and subscriber applications. Technically, it briefly displays the contents in accordance with the following table.
No Title Description
1 Dimension Height H = 2200-2500 mm
Width W = 800-1600 mm
Depth D = 1100-1700 mm
2 Color RAL 7032
3 Protection Degree IP 41-42
4 Standard IEC 298
5 Rated (Named) Voltage 6 kv, 12 kv, 20 kv, 32 kv
6 Rated (Named) Ampere 630A
7 Short-Circuit Current 25 kA, 1s

8

Frequency 50 Hz
